Auto-Documenting MikroTik Switch Ports with Ansible and LLDP Neighbours

One of the small but persistent annoyances of managing network switches is keeping port labels up to date. You cable something up, then six months later you’re staring at a list of qsfp28-1-2 entries wondering what’s plugged into what. This post covers a short Ansible playbook I wrote to solve that problem on my MikroTik switches — it pulls LLDP neighbour data directly from the switch and writes it back as interface comments, giving you a self-updating port map with no manual labelling required.

The Problem

MikroTik RouterOS supports IP Neighbour Discovery (which covers both LLDP and CDP), and any device that advertises itself — ESXi hosts, other switches, routers — will show up in the neighbour table with its hostname (identity). The information is already there on the switch; it’s just not surfaced anywhere obvious in a persistent way. Interface comments are the natural place to put it, but updating them by hand every time something changes is tedious and inevitably falls behind.

The Playbook: update_interface_comments.yml

The playbook runs in two plays. The first ensures the Python library librouteros is present on the Ansible controller (required by the community.routeros.api modules). The second does the actual work against the switches.

---- name: Ensure controller has librouteros  hosts: localhost  connection: local  gather_facts: false  tasks:    - name: Install librouteros pip package      ansible.builtin.pip:        name: librouteros        state: present- name: Update Mikrotik interface comments from LLDP/discovery neighbours  hosts: mikrotik  gather_facts: false  ...

All RouterOS API calls share a common set of connection defaults via module_defaults, keeping the individual tasks clean:

  module_defaults:    group/community.routeros.api:      hostname: "{{ ansible_host }}"      username: "{{ ansible_user }}"      password: "{{ ansible_password }}"      tls: false      validate_certs: false

Step 1 — Fetch neighbours and interfaces

Two tasks pull data from the switch over the RouterOS API:

    - name: Fetch discovery neighbours      community.routeros.api:        path: "ip neighbor"      register: neighbours    - name: Fetch interfaces      community.routeros.api_info:        path: interface      register: interfaces

The neighbour table returns entries with fields like interface, identity, address, and mac-address. The interface list gives us every interface on the switch.

Step 2 — Build a lookup map

A set_fact task distils the neighbour list down to a simple dictionary mapping interface name → neighbour identity:

    - name: Build interface -> neighbour identity map      ansible.builtin.set_fact:        neighbour_map: >-          {{            dict(              _items | map(attribute='interface')              | zip(_items | map(attribute='identity'))            )          }}      vars:        _items: >-          {{            neighbours.msg            | selectattr('interface', 'defined')            | selectattr('identity', 'defined')            | rejectattr('identity', 'equalto', '')            | list          }}

The filters here do a few important things:- Only include neighbours that have both an interface and an identity field.- Drop entries where identity is an empty string (devices that respond to discovery but don’t broadcast a hostname).- The result looks something like {"qsfp28-1-2": "esxi-host-01", "qsfp28-1-3": "esxi-host-02"}.

Step 3 — Write LLDP comments back to interfaces

The main update task loops over every interface and, for any that appear in the neighbour map, writes a comment in the format LLDP: <identity>:

    - name: Update interface comment from neighbour identity      community.routeros.api_find_and_modify:        path: interface        find:          name: "{{ item['name'] }}"        values:          comment: "{{ comment_prefix | default('LLDP') }}: {{ neighbour_map[item['name']] }}"      loop: "{{ interfaces.result }}"      loop_control:        label: "{{ item['name'] }}"      when:        - item['name'] in (neighbour_map | default({}))        - item['name'] not in (static_interface_comments | default({}))        - item['name'] | regex_search('^(' + (skip_interfaces | default(['lo', 'bridge', 'vlan'])) | join('|') + ')') == none

Three when conditions control which interfaces get updated:

1. Must have a neighbour — skip interfaces with nothing plugged in or nothing advertising.
2. Not in the static list — interfaces with manually defined comments are left alone.
3. Not a virtual interface — logical interfaces (loopback, bridge, vlan) are skipped by default via skip_interfaces.

The comment_prefix variable defaults to LLDP but can be overridden per host if you want a different label format.

Step 4 — Apply static overrides

Devices that don’t speak LLDP (TrueNAS SCALE is a common example) need manual labels. A final task applies these from a per-host variable file, and because it runs after the LLDP pass, static comments always win:

    - name: Apply static interface comments      community.routeros.api_find_and_modify:        path: interface        find:          name: "{{ item.key }}"        values:          comment: "{{ item.value }}"      loop: "{{ static_interface_comments | default({}) | dict2items }}"      loop_control:        label: "{{ item.key }} -> {{ item.value }}"

Variable Files

host_vars/mikrotik-sw-1/interface_comments.yml

This is where static labels live for any port whose device doesn’t advertise via LLDP:

static_interface_comments:  # Storage (no LLDP advertisement)  qsfp28-1-4: "StoreServ1"  qsfp28-2-4: "StoreServ2"  # Workstations  qsfp28-2-2: "Z840-1"  qsfp28-2-3: "Z840-2"

Comments here are written verbatim — no LLDP: prefix is added. This lets you use whatever friendly label makes sense for the device.

Running the Playbook

# Update all switchesansible-playbook -i inventory.yml update_interface_comments.yml# Update a single switchansible-playbook -i inventory.yml update_interface_comments.yml --limit mikrotik-sw-1

After it runs, opening Interfaces in Winbox or running /interface print in the RouterOS terminal will show the neighbour hostnames in the Comment column. The result is an always-current port map that updates itself whenever you re-run the playbook.

Inventory

The playbook targets two MikroTik switches defined in inventory.yml:

Both connect via SSH key authentication using the admin user.

Prerequisites

Install the required Ansible collections before running:

ansible-galaxy collection install community.routeros ansible.netcommonpip install librouteros

The librouteros pip dependency is also handled automatically by the first play in the playbook, so it’s covered even if you forget.

Summary

The playbook does four things in sequence:

1. Queries the RouterOS neighbour table over the API.
2. Builds a map of interface → LLDP identity.
3. Writes LLDP: <hostname> comments to any interface that has a neighbour, skipping virtual interfaces and any port already covered by a static override.
4. Applies static comments for devices that don’t advertise via LLDP.

The full playbook and variable files live in the ansible/mikrotik repository alongside the backup and provisioning playbooks for the same switches.
